Specifications
Element		Single Place SNS-8	Two Place SNS-9
Wing Span		22' 0"	23' 4"
Length		15' 6"	18' 0"
Height		5' 3"	5' 4"
Wing Area		140 sq ft	148 sq ft
Engine		MZ 201	503 Rotax
Fuel Capacity		5 gal	10 gal
Empty Weight		247 lbs	360 lbs
Gross Weight		500 lbs	814 lbs
Useful Load		253 lbs	454 lbs
Time to Build with Standard Assembly Package		100 - 150 hrs	200 - 300 hrs
Performance Chart
Element	Single Place SNS-8			Two Place SNS-9
Never Exceed Speed	98 mph			113 mph
Maximum Cruise	60 mph			85 mph
Range at Maximum Cruise	180 miles			300 miles
Stall/Landing Speed	27 mph			39 mph
Takeoff Distance (grass)	175 feet			300 feet
Landing Roll with Brakes	175 feet			300 feet
Rate of Climb @ 40 mph	700 ft/min			600 ft/min
Glide ratio (engine off)	12:1			12:1
Rate of Sink	250 ft/min			325 ft/min
Load Factor	6.0+/3.0-			3.8+/1.9-
