SPECIFICATIONS
|
Vulcan
|
|
Powerplant
|
52 hp
R503 x 2 (104 hp)
|
|
Length, m/ft
|
6.9/22.6
|
|
Height, m/ft
|
1.9/6.4
|
|
Wingspan, m/ft
|
11.4/37.4
|
|
Wing area, sq. m/sq. ft
|
15.7/169
|
|
Wing loading
|
7 lbs per sq. ft
|
|
Power loading
|
11.5 lbs per hp
|
|
Seats
|
2
|
|
Cabin length m/inches
|
2.1/82.8
|
|
Cabin width m/inches
|
.64/25.2
|
|
Cabin height m/inches
|
1.2/46.8
|
|
Empty weight, kg/lb
|
300/660
|
|
Max. Gross weight, kg/lb
|
550/1210
|
|
Useful load, kg/lb
|
295/550
|
|
Fuel capacity, standard, l/gal
|
90/23.9
|
|
Take off distance, ground roll, m/ft
|
50/164
|
|
Rate of climb at sea level, mps/fpm
|
6/1200
|
|
Cruise speed, kph/mph
|
145/90
|
|
Range, km/miles
at speed, kph/mph
|
320/200
130/90
|
|
Endurance, hrs (rpm)
|
5/4000
|
|
Landing distance, ground roll m/feet
|
91/300
|
|
|
|
|
Vne (never exceed), kph/mph
|
220/137
|
|
Vso (stall, landing config) kph/mph
|
55/34
|
|
