CORVAIR
O-164 O-190
Direct
Drive Corvair Engine Spec Sheet
|
|||
Engine Model
|
O-164
|
O-190
|
|
Number of Cylinders |
Six |
Six |
|
Cooling |
Air |
Air |
|
Displacement |
164 cubic inches (2,700cc) |
190cid (3,100cc) |
|
Bore |
|
94mm |
|
Stroke |
|
75mm |
|
Compression Ratio |
9:1 |
9:1 |
|
Oil Capacity |
4.5 - |
4.5 - |
|
Weight Wet, Ready
to Fly with Electric Start |
Approximately 220- |
Approximately 212- |
|
Length |
Approx. |
Approx. |
|
Width |
|
|
|
Performance
|
|||
HP |
100@3,150 rpm |
120@3,200 |
|
HP (Continuous) |
90@3,000 rpm |
110@3,000 |
|
Torque |
|
|
|
Fuel |
93 Octane Auto Gas
or 100 LL |
93 Octane Auto Gas
or 100 LL |
|
Fuel Flow |
5.6 GPH @ 75% |
7.0 GPH @ 75% |
|
Accessories
|
|||
Oil Cooler |
Stock Corvair-Block Mounted, Can Be Remoted
|
||
Ignition |
Dual Ignition, Single Plugs |
|
|
Generator |
Alternator - 14
Amp std., Larger Available |
|
|
Starter |
Hand Prop or
Electric Start; Electric Start adds |
|
|
Prop Flange |
SAE #1 |
|
|
Prop Rotation |
Left Hand, Right
Hand Optional |
|
|
Recommended Prop Diameter |
Wood to 68"; Composite
to 72"; |
|
|
Induction |
Carbureted |
|
|
Fuel Pump |
Mechanical, Stock Corvair |
|
|
Note:
Horsepower and
Torque measured on dynamometer with air cleaner, full exhaust system and
quiet muffler installed. Using a less restrictive exhaust system can exceed
these numbers by 5%. Turbo boosting is available on either motor; 5 psi will increase output by 25% on both motors with a
weight increase of approximately |
|
